Flute Laminating Machine

Our High Speed Flute Laminating Machine, a cutting-edge solution that combines an Automatic Flute Laminating Machine with advanced motion control and servo correction technology. Equipped with photoelectric sensors for precise alignment, this Servo Flute Laminating Machine ensures accurate positioning of top and bottom sheets. Its user-friendly design allows for simple operation; just input the paper size, and our Intelligent Flute Laminating Machine automatically adjusts. Experience efficiency and reliability with our Automatic Flute Laminator, perfect for all your lamination needs.

High precision and speed:one-touch commissioning in 20 seconds

Maximum speed 150 meters/minute:increase productivity with fast laminating speed.

Intelligent:multiple models to adapt to various flute types and meet different packaging needs.

Automatic pressure adjustment and glue adjustment:ensure precise alignment and promote seamless cardboard bonding

More >>

YB-1450HGS/1650HGS High Speed Laminating Machine and Flip Flop Stacker

1. Top Sheet Stream Feeding With Side Pulling Ball Positioning
2. Casting Frame,Full Servo Motor Control
3. Auto Collecting.Front And Back Placed Stacking

More >>

YB-1450HG/1650HG Intelligent flute laminating machine

1. AUTO PRESSURE ADJUSTMENT、AUTO GLUE ADJUSTMENT

2. MAX SPEED 200M/MIN

3. CASTING FRAME 40MM, LARGE DIAMETER ROLLER TRANSMISSION 165MM

4. CARDBOARD TO FLUTE & CARDBOARD TO CARDBOARD

5. TOP SHEET STREAM FEEDING WITH SIDE PULLING BALL POSITIONING

6. FULL SERVO MOTOR CONTROL(9 SERVO MOTORS)

More >>

YB-1450HS/1650HS Servo Laminating Machine and Flip Flop Stacker

1. Auto Collecting. Front And Back Placed Stacking
2. Save Time And Effort, Simple And Easy To Learn
3. Servo Compensation Positioning Automatic Tracking System

More >>

YB-1450H/1650H Cardboard Flute Laminator Machine

1.Top Sheet Thickness: 120-500g

2.Precision:±1mm

3.Max Sheet Size:1450×1450mm

4.Min sheet size: 380*350mm

5.Mas speed: 150m/min

More >>

YB-1150F/1450F/1650F Servo Type Laminating Machine

1. Motion control and servo systems ensure accurate paper positioning.
2. Automatically adjusts with just the paper size input.
3. Multiple sensors provide precise laminating alignment.

More >>

Automatic 5ply Flute Laminating Machine

1.Max size: 1450*1450mm

2.Min size: 380*350mm

3.Top Sheet Thickness: 120-500g

4.Max speed: 120m/min

5.Acuracy: +/-1mm

More >>

YB-1300ES/1450ES/1650ES Automatic Flip Flop Laminating Machine

1. High precision paper feeding mechanism
2. Bottom and top paper automatic tracking
3. Non-stop collection make continuous production

More >>

YB-1300E/1450E/1650E Cardboard to Flute Laminating Machine

1.Top Sheet Thickness:150-600g

2.Max Speed: 6000 Sheets/hour

3.Fitting Precision: ±1mm

More >>

YB-1100B/1300B/1450B/1650B Semi Automatic Flute Laminator

1. Automatic paper lifter (To Choose)
2. Single feeding, bottom sheet feeding automatic, unilateral regulation, water roller cleaning.
3. High feeding table, easy paper adding

High-Quality Requirements:

Use Of Internationally Renowned Accessories

Vacuum pump (Brand: Becker, Germany)

Internationally renowned brands

Precision design and solid structure

Light weight, easy to install and maintain

Use of air cooling

Value-jointed drive

Contains high-efficiency oil mist filter

Low vibration and low noise

Suitable for a variety of environment

High wind pressure, stable performance

Long service life and easy maintenance

Environmentally friendly

Frequency converter (Brand: Siemens，Germany)

The advantages of German Siemens inverters mainly include: internationally renowned brand, energy saving, advantages in motor operation, powerful functions, high reliability and good flexibility.

Servo Motor( Brand:YASKAWAN ,Japan)

The advantages of Japan's Yaskawa servo motors are mainly reflected in high brand awareness, high performance, environmental protection and efficiency, high-precision control, energy-saving system construction, quick response and rich functional features.

Flute Laminating Machine FAQ

1450H and 1150F

1450E

1450W

1207BK/1210BK

1.What is the Max speed of this model?

150m/min

2.What is the Min weight of the top sheet?

120gsm

3.What is the Max thickness of the bottom paper?

9-10mm thickness

4.Does this model can do cardboard paper to cardboard paper?

Yes, it can do. This model can do both cardboard to cardboard and cardboard to flute.

5.How many days for the production?

40 days.

6.What is the payment terms?

30% deposit by TT and 70% balance by TT before container loading.

1.Which glue doese this machine use?

Corn starch glue or white glue

2.What is the Max speed of this model?

90m/min

3.Which paper can do as the top sheet?

Duplex paper and cardboard paper from 175-500gsm,the Kraft paper from the 145-450GSM

4.which paper can do as the bottom paper?

Two Layers: A/B/C/E/F corrugated paper

Four layers: AB/BB/BE/BE/EE corrugated paper

Grey board paper from the 600GSM to 1800GSM

1.what’s the weight of the top paper?

From 120-500gsm

2.Which paper can be used for the bottom paper?

A B C E F corrugated paper, 4 ply corrugated paper, cardboard paper above 350gsm.

3.How many servo motors in this machine?

Nine Servo Motors.

4.Pressure can be adjusted automatically?

Yes, both glue and roller pressure can be adjusted automatically.

1.What is the max and Min size for this model?

Max: 1200*720mm/1200*1000mm

Min: 450*280mm

2.what is the weight for top and bottom paper?
